ElectraStat ESD Rubber Flooring Specifications
Avoid electrostatic discharge and its unforeseeable consequences.
|
Specifications:
DIMENSIONS:
Thicknesses Available:
(ES-C2012, ES-C2013, ES-C2014, ES-C2015, ES-C2016)
 ~ 12.2 m x 1.22 m/
~39.3' x 48"
 ~ 61 cm x 61 cm/
~24" x 24"
|
For access floor panels:
~ 61.5 cm x 61.5 cm/
~24.2" x 24.2" |
Technical Data:
Resistance to ground: Rtg < 106Ohm according to
ESD S7.1,
ASTM F-150
Conform to: ASTM-F-1344 – ESD Rubber Floor Tile
ASTM-F-1859 – ESD Rubber Sheet Flooring without Backing
ASTM-F-1860 – ESD Rubber Sheet Flooring with Backing
| Test |
Average Test Results |
| Limited Conductivty Warranty in Years(a) |
10 |
| Limited Wear Warranty in Years |
5 |
Taber Abrasion Test
According to ASTM D-3389
H-18 Wheel (1000 cycles)
500 gram load – grams weight loss |
<.7 |
| Extra Heavy Traffic (Forklift up to 850 psi) |
No |
| Shore Hardness “A“ ASTM D-2240 |
≤.85" |
Static Load Limit 1,000 Lbs./Sq. In
ASTM F-970 Residual Compression |
≤.003" |
Static Coefficient of Friction ASTM
D 2047-82 (min. .5) |
ADA
Slip Resistance (Tiles, Sheets, Stairtreads) ≥.6
Inquire standard products for ramps where ≥ .8 is required. |
Critical Radiant Flux ASTM E-648
(not less than .45 W/per cm2) |
Class 1 |
| NBS SMOKE DENSITY ASTM E-662 |
<450 |
| Cigarette burn and solder resistance |
Yes |
| Halogen-free |
Yes |
Resistance to: – acids – alkalies –
solvents – other chemicals (1) |
Excellent, Call for Specifics |
| Oil and grease resistance |
No |
Static Generation Comparison
Less than 10 Volts per ESD STM 97.2* (c) ANSI/ESD S20.20 |
< 10 |
ESD-S7.1/ASTM F-150/iec 61340-5-1
(RH >30% at room temperature)
10 Year Limited Conductivity
Warranty (a)(ohms) |
< 1 x 106 |
| Decay-time FTM 101 C 4046 (sec.) |
<.025 |
| Compliance with Art. 15, Part 1120 State of N.Y. Fire Bulding Code DOS file # 09650-900613 |
(d) |
|
