ZeroStat TractionStat II

ZeroStat TractionStat II is a heterogeneous vinyl sheet floor covering with a compact calendared backing and flexible reinforce glass fleece innerlayer for dimensional stability. The scratch resistant PUR wearlayer contains colorfast pigments, transparent PVC chips and carborundum granules.

colors:

PHYSICAL CHARACTERISTICS: (DIMENSIONS ARE APPROXIMATE):

Width: 79" (2 Meters)
Length: 82 Linear Feet (25 Meters)
Gauge: 0.080" (2.0 mm)
Roll Size: 60 yards² (50 meters²)

PRODUCT PERFORMANCE AND TECHNICAL DATA:

Reference Specification: ASTM F-1303 Type 1, Grade 1, Class B Backing

Static Load Limit: 850 Pounds Per Square Inch when tested in accordance with ASTM F-970-00, Standard Test method for Static Load Limit.

Environmental:

Compliant with CHPS 01350 requirements for VOC emissions and indoor air quality.
Contributes to the following LEED® v4 credits:
Materials & Resources
Credit 4, Option 2: Recycled Content (18% Pre-Consumer)
Prerequisite 2: 100% Recyclable Core and Stopper
Indoor Environmental Quality
Credit 2: Low-Emitting Materials

Tensile Strength: ASTM D-638: 673 p.s.i.

Slip Resistance: Meets or exceeds Federal Standards and A.D.A. recommendations of .6 for flat surfaces.

Fire Resistance:
ASTM E-648/NFPA 253 (Critical Radiant Flux)--Class 1.
Meets 450 or less when tested in accordance with ASTM E 662/NFPA 258, Standard Test method for Resistance to Chemicals of Resilient Flooring.

FAA Vertical Flammability: Meets or exceeds.

Dimensional Stability: Meets or exceeds ASTM F-1303.

Light Fastness: Most Colors achieve a 6 on the Blue Scale (Blue scale maximum is 8).

Castor Resistance: During 30,000 cycles of a wheel loaded with 150 pounds. No damage.

Electrical Resistance:
ASTM 150/ EOS/ESD S7.1
<1 x 10¹⁰ (With System Requirements)

System Requirements:
GZ-C2001 — 1-part, full surface conductive adhesive mechanism
TP-7521 — Copper foil underlayment grounding grid tape
SP-GNDPLT-ASM — Stainless steel ground termination plates
WR-COLOR — 1/8” Welding bead for seamles
ZS-DIASEAL-XL — ESD floor glaze/sealer
